Glass Substrate Transfer Conveyor

Specifications and Features

Purpose/Function

Transport/Movement Drive/Actuation

Roller conveyor with O-ring
Conveying glass substrates using rollers with O-rings at the contact points

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Deep Groove Ball Bearing	C-E6202ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring Material: Steel Basic dynamic load rating (N): 5430 Allowable rotational speed (RPM): 8000	1	SGD 1.38/Unit
②	Deep Groove Ball Bearing	C-E6000ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring Material: Steel Basic dynamic load rating (N): 3190 Allowable rotational speed (RPM): 8000	16	SGD 1.02/Unit
③	Parallel Key	C-KES5-30	Shape: Parallel key (rounded on both ends) Width (mm): 5 Total length (mm): 25 Material: Steel	1	SGD 0.60/Unit
④	Parallel Key	C-KES5-20	Shape: Parallel key (rounded on both ends) Width (mm): 5 Total length (mm): 30 Material: Steel	1	SGD 0.44/Unit
⑤	Deep Groove Ball Bearing	C-E6201ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring Material: Steel Basic dynamic load rating (N): 4270 Allowable rotational speed (RPM): 8000	2	SGD 1.20/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Ball Bearing SGD 1.02 /Unit Shipping: Same Day

2 Parallel Keys Straight / Round at One End / Round at Both End SGD 0.33 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
