Winder Detachable Roller
Specifications and Features
- Purpose/Function
-
Transport/Movement
A roller that rolls up unnecessary land after attaching stickers and other attachments
Easy removal of rollers for simple collection and disposal of the wound backing material.
The roller is divided into two parts, making it easier to remove the wound backing material.
When pulling the handle to remove the roller, remove the end cap held by the ball plunger and avoid pulling hard on the connected roller.
Easy removal of rollers for simple collection and disposal of the wound backing material.
The roller is divided into two parts, making it easier to remove the wound backing material.
When pulling the handle to remove the roller, remove the end cap held by the ball plunger and avoid pulling hard on the connected roller.
※ This example is for design reference only. Equipment components may differ from the actual shape.
| No. | Component | Economy Type Number | Specification | Quantity | Unit Price |
|---|---|---|---|---|---|
| ① | Handle | C-NUWANCS7-68 | Mounting pitch L(mm): 68 Material: Stainless steel Surface treatment: Buff polishing |
1 | SGD 2.56/Unit |
| ② | Ball Plunger | C-NBSX5-20P | Material: Stainless steel (body), Resin (ball) Outer diameter M(mm): 5 Stroke (S)(mm): 1 Load range (N): 4~20 |
1 | SGD 14.14/Unit |
| ③ | Ball Roller | C-BCHA15 | Shaft diameter D1(ø): 15 Load capacity (N): 44 Main body material: Stainless steel Ball material: Stainless steel |
4 | SGD 6.88/Unit |
※ Kindly check MISUMI eCatalog for latest information.
Product List
1
2
3
※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
