Shaft Press-Fit Jig

Specifications and Features

Purpose/Function

Positioning/Clamp Setup

Adsorbing a stainless steel shaft and pressing it into a resin part.
Manually activate the vacuum generator, release the index plunger holding the pin, and lower the suction unit.
Manually press pins into positioned workpieces.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Index Plunger	C-PMXK6M	Lock mechanism: Return type Main body material: Steel Tip material: Stainless steel Stroke S(mm): 4	1	SGD 2.52/Unit
②	Set Screw	E-GMSSFS3-4	Screw nominal (M): 3 Length L(mm): 4 Material: Stainless steel RoHS10 compliant	1	SGD 0.04/Unit
③	Set Screw	E-GMSSFS4-5	Screw nominal (M): 4 Length L(mm): 5 Material: Stainless steel RoHS10 Compliant	1	SGD 0.04/Unit
④	Round Pillar	C-PETGR10-20	Outer diameter D(φ): 10 Length L(mm): 20 Post type: Solid Material: Steel Surface treatment: Nickel plating	4	SGD 1.04/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Knob Plunger Standard Type Coarse Thread SGD 2.48 /Unit Shipping: Same Day

2 Hex Socket Set Screws - Flat End, Stainless Steel, Box / Single Item[RoHS Compliant] SGD 0.04 /Unit Shipping: 4 Days

3 Round Posts One End Threaded, One End Tapped SGD 0.84 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
