Rotary Cutting to Conveyor

Specifications and Features

Purpose/Function

Transport/Movement

Cut continuously flowing workpieces and transfer them to a pitched conveyor.
Workpieces flow continuously on a two-row timing belt conveyor and are transferred to the next process's pitched conveyor by rotary cutting.
The pitched conveyor detects incoming workpieces with sensors and advances them by one pitch.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Deep Groove Ball Bearing	C-E6001ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring Material: Steel Basic dynamic load rating (N): 3570 Allowable rotational speed (RPM): 8000	2	SGD 1.09/Unit
②	Locking Fixed Bearing Nut	E-BNR12	Screw nominal M(φ): M12×1.0 Material: Steel Surface treatment: Black oxide coating Screw type: Metric (fine) thread	1	SGD 4.75/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Ball Bearing SGD 1.02 /Unit Shipping: Same Day

2 Loosening Prevention Nuts for Bearing SGD 2.43 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
