Direct-Acting Guide by Shaft and Linear Bushing

Specifications and Features

Purpose/Function

Transport/Movement

Guides linear motion driven by cylinders, etc.
As it has a flange shape, it is mounted on the housing with bolts; stroke adjustment and stopping are possible using a set collar.
The housing and bushing are integrated, with holes drilled for mounting other parts.
Moving parts (e.g., tables) can be operated without considering the shape of the housing.

Direct-Acting Guide by Shaft and Linear Bushing

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Linear Bushing - Round Flange	E-LBF12UU	Inner circle diameter dr(φ): 12 Total length L(mm): 30 Outer tube material: Iron Outer tube surface treatment: None	1	SGD 4.10/Unit
②	Linear Bushing - Straight	C-LMU-N12	Inner circle diameter dr(φ): 12 Total length L(mm): 30 Outer tube material: Iron Outer tube surface treatment: None	1	SGD 2.50/Unit
③	Linear Bushing Housing Unit	E-LBHN12	Inner circle diameter dr(φ): 12 Total length L(mm): 36 Outer tube material: Steel Housing unit material: Aluminum alloy	1	SGD 4.90/Unit
④	Linear Bushing - Square Flange	E-LBKP12DMUU	Inner circle diameter dr(φ): 12 Total length L(mm): 47 Outer tube material: Iron Outer tube surface treatment: Electroless nickel plating	1	SGD 18.21/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Round Flanged Linear Bushings, Single / Double / Opposite Counterbored Hole SGD 3.32 /Unit Shipping: Same Day

2 Linear Bushing - Standard, Single[RoHS Compliant] SGD 2.10 /Unit Shipping: Same Day

3 Linear Bushing Housing Units-Wide Blocks, Single / Medium SGD 4.10 /Unit Shipping: Same Day

4 Square Flanged Linear Bushings With Pilot, Medium SGD 18.21 /Unit Shipping: 5 Days

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
