Ball Screw and Support Unit
Cost reduction with economical parts and design time reduction, quality assurance, cost reduction

Specifications and Features
Purpose/Function
Transport/Movement Setup

Fixed support for the shaft when operating the ball screw.
Installation is possible on a fixed surface perpendicular to the ball screw axis direction using a square support unit.
By using a nut bracket, moving parts (e.g., tables) can be installed without considering the shape of the housing.
Mountable on the ball screw axis using a circular support unit.
Ball Screw and Support Unit
※ This example is for design reference only. Equipment components may differ from the actual shape.
No. Component Economy Type Number Specification Quantity Unit Price
① Support Unit - Fixed Side C-TBK12 Type: Fixed side
Shaft diameter D(φ): 12
Material: Steel
Surface treatment: Black oxide coating		 1 SGD 24.22/Unit
② Support Unit - Supported Side C-TEF12 Type: Support side
Shaft diameter D(φ): 10
Material: Steel
Surface treatment: Black oxide coating		 1 SGD 8.32/Unit
③ Support Unit - Fixed Side C-TFK12 Type: Fixed side
Shaft diameter D(φ): 12
Material: Steel
Surface treatment: Black oxide coating		 1 SGD 25.08/Unit
④ Support Unit - Supported Side C-TFF12 Type: Support side
Shaft diameter D(φ): 10
Material: Steel
Surface treatment: Black oxide coating		 1 SGD 7.26/Unit
※ Kindly check MISUMI eCatalog for latest information.

Product List

Support Units for Ball Screw, Fixed Side Narrow Pitch Square Type1 Support Units for Ball Screw, Fixed Side Narrow Pitch Square Type SGD 23.68/Unit Shipping: Same Day
Support Units for Ball Screw, Support Side Square Type2 Support Units for Ball Screw, Support Side Square Type SGD 8.16/Unit Shipping: Same Day
Support Units for Ball Screw, Fixed Side Round Type3 Support Units for Ball Screw, Fixed Side Round Type SGD 23.02/Unit Shipping: Same Day
Support Units for Ball Screw, Support Side Round Type4 Support Units for Ball Screw, Support Side Round Type SGD 7.16/Unit Shipping: Same Day
※ The price on the product list is the starting price for that product.
    Product details (Price, leadtime and availability) may be subjected to updates.
    Kindly check MISUMI eCatalog for latest information.
