Chuck Mechanism Using Left and Right Screws

Specifications and Features

Purpose/Function

Positioning/Clamp

Using the left and right screws, the motor drives the rotation to determine the chuck or position.
Long stroke and chuck power (gripping force) that cannot be handled by commercial products can be changed.

Chuck Mechanism Using Left and Right Screws

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	30° Trapezoidal Nut Support Unit	C-MDWZ10	Type: Fixed side Support shaft diameter (φ): 10 Material: Steel Surface treatment: Black oxide coating	1	SGD 24.16/Unit
②	30° Trapezoidal Nut	C-MTSBHRC14	Screw nominal diameter D(φ): 14 Pitch (mm): 3 Material: Copper alloy Surface treatment: None	1	SGD 33.84/Unit
③	30° Trapezoidal Nut Support Unit	C-MDUZ10	Type: Fixed side Support shaft diameter (φ): 10 Material: Steel Surface treatment: Black oxide coating	1	SGD 11.62/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Lead Screw Support Units Fixed Side Square Type SGD 23.09/Unit Shipping: Same Day

2 Lead Screw Nuts Wide Block SGD 24.74/Unit Shipping: Same Day

3 Lead Screw Support Units Support Side Square Type SGD 10.57/Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
