Precision Visual Inspection Using Camera
Cost reduction with economical parts and design time reduction, quality assurance, cost reduction

Specifications and Features
Purpose/Function
Transport/Movement Positioning/Clamp Inspection/Measurement

Reproducibility of positioning of manual jigs.
Set the workpiece and secure it with a toggle clamp, then visually inspect the monitor image using a camera.
Toggle clamps are selected as top and bottom types for workpieces that can only be held by their upper and lower surfaces.
Environment/Operability: A mechanism that sets the workpiece in a wide space using a linear guide, moves it under the camera, and secures it with a toggle clamp.
Precision Visual Inspection Using Camera
※ This example is for design reference only. Equipment components may differ from the actual shape.
No. Component Economy Type Number Specification Quantity Unit Price
Toggle Clamp C-LD-201HB Clamp bolt size: M5
Material: Steel (body), Steel (bolt)
Clamping pressure (N): 400
1 SGD 2.46/Unit
Set Screw E-GMSSU5-8 Screw nominal (M): 5
Length L(mm): 8
Material: Stainless steel
RoHS10 Compliant
2 SGD 0.04/Unit
Toggle Clamp C-LD-201A Clamp bolt size: M4
Material: Nylon (body), Nylon (bolt)
Clamping pressure (N): 264
2 SGD 1.92/Unit
※ Kindly check MISUMI eCatalog for latest information.
※ The price on the product list is the starting price for that product.
    Product details (Price, leadtime and availability) may be subjected to updates.
