Flat Suction Hand

Specifications and Features

Purpose/Function

Transport/Movement Positioning/Clamp

A structure that allows the suction size to be changed by switching the suction pad system.
Designed for a robot equipped with a hand capable of lifting various types of panels using multiple suction pads.
Use an aluminum frame to reduce the hand's weight, with suction pads arranged in two rows on each side (four rows total) to accommodate various workpiece sizes.
Environment/Operability: Automated mechanism that lifts workpieces with multiple suction pads.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	End Cap for Aluminum Frame	LCEC6-2020-B	Material: Nylon Frame size: 2020 Frame dimensions: 2020	160	SGD 0.28/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 End Caps For Aluminum Frames SGD 0.28 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
