Swing Clamp

Specifications and Features

Purpose/Function

Positioning/Clamp Drive/Actuation Processing

Rotate to clamp the workpiece.
Rotate the workpiece, clean dust from its surface, place it on the turntable, then rotate and lower the arm to clamp the workpiece.
Ensure the clamp arm swivels 45° to avoid interference when setting the workpiece.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Deep Groove Ball Bearing	C-E6206ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring Material: Steel Basic dynamic load rating (N): 13650 Allowable rotational speed (RPM): 8000	2	SGD 3.67/Unit
②	Rod End Bearing	E-GYN10A	Main body material: Steel Connection screw M: M10×1.25 Connection screw direction: Right-hand thread	1	SGD 2.73/Unit
③	Cam Follower	C-CFUA6-16	Screw part nominal (M)(mm): M6×1.0 Material: Carbon steel Fastening method: With hexagonal hole in head Basic load rating Cr(dynamic)(kN): 3.3 Allowable rotational speed (rpm): 14000	2	SGD 7.51/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Ball Bearing SGD 1.02 /Unit Shipping: Same Day

2 Rod End Bearings Tapped SGD 1.80 /Unit Shipping: Same Day

3 Cam Followers Crown,Hex Socket SGD 6.60 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
