OLED Cell Cutting Device

Specifications and Features

Purpose/Function

Transport/Movement Assembly/Processing Inspection/Measurement

Actuator designed for dust resistance and ease of grease maintenance.
Cut the cell to a size suitable for smartphones
To prevent glass dust after cutting, the upper mechanical parts are designed with dustproof specifications.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Coupling	C-SCPW21-6-8	Outer diameter A(φ): 21 Allowable torque range (Nm): 0.05~1.00 Allowable eccentricity range (mm): 0.02~0.2 Maximum rotational speed (r/min): 10000	1	SGD 52.18/Unit
②	Trim for Aluminum Frame	LMUSB8	Series: Groove width 8mm Length L(mm): 2000 Material: PVC	3	SGD 2.00/Unit
③	Coupling	C-SCPW34-10-14	Outer diameter A(φ): 34 Allowable torque range (Nm): 3.01~5.00 Allowable eccentricity range (mm): 0.02~0.2 Maximum rotational speed (r/min): 10000	1	SGD 67.73/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Disc Couplings High Regidity Double Disc, Clamping Type SGD 52.18/Unit Shipping: Same Day

2 U Shape Groove For Aluminum Frames SGD 2.00/Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
