Sheet Transfer Dancer Roll

Specifications and Features

Purpose/Function

Supply/Discharge Ejection/Accumulation Drive/Actuation

Tension control of sheet rolls
Controls tension via a dancer mechanism in the sheet feed section and maintains constant tension after adjustment.
The dancer stops if the feed and rewind speeds are the same.
Environment/Operability: Used in sheet-type work supply section; sheet rolls are changed manually.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Low Head Hex Socket Bolt	E-GCBSST3-8	Screw nominal (M): 3 Length L(mm): 8 Material: Stainless steel RoHS10 compliant	4	SGD 0.08/Unit
②	Deep Groove Ball Bearing	C-SE694ZZ	Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring material: Stainless steel Basic dynamic load rating (N): 360 Allowable rotational speed (RPM): 8000	10	SGD 1.27/Unit
③	Linear Bushing - Straight	C-LMUW5	Inner circle diameter dr(φ): 5 Total length L(mm): 28 Outer tube material: Iron Outer tube surface treatment: None	2	SGD 5.13/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Hex Socket Low Head Cap Screw - Stainless Steel, Small Box / Single Item Sale[RoHS Comliant] SGD 0.04/Unit Shipping: 4 Days

2 Small Ball Bearings Stainless Steel SGD 1.11/Unit Shipping: Same Day

3 Linear Bushing - Standard, Double[RoHS Compliant] SGD 5.13/Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
