Table Channel Conveying Mechanism
Specifications and Features
- Purpose/Function
-
Transport/Movement
Drive/Actuation
Tact time reduced by half with a two-tier table.
A mechanism that operates a shuttle on a two-stage table that transfers work, converting rotary motion into linear motion using a motor and timing belt.
By rotating the motor, you can achieve two types of belt travel directions, with a table fixed to each.
Environment/Operability: An automatic mechanism that drives two tables with a single driving mechanism.
A mechanism that operates a shuttle on a two-stage table that transfers work, converting rotary motion into linear motion using a motor and timing belt.
By rotating the motor, you can achieve two types of belt travel directions, with a table fixed to each.
Environment/Operability: An automatic mechanism that drives two tables with a single driving mechanism.
※ This example is for design reference only. Equipment components may differ from the actual shape.
| No. | Component | Economy Type Number | Specification | Quantity | Unit Price |
|---|---|---|---|---|---|
| ① | Mechanism for Open-End Timing Belt | C-TBCR-S5M250 | Belt shape: Belt end fitting Belt width (mm): 25 Applicable belt type name: S5M |
2 | SGD 4.44/Unit |
| ② | Timing Belt S5M | C-HTBN1350S5M-250 | Belt type: S5M Belt material: Chloroprene rubber Belt type: Circular tooth super torque Belt width (mm): 25 Number of teeth: 270 |
1 | SGD 15.26/Unit |
| ③ | Idler S5M | C-AHTFW28-S5M250-10 | Usable belt width (mm): 25 Material: Aluminum alloy Surface treatment: White anodizing |
1 | SGD 30.96/Unit |
| ④ | Deep Groove Ball Bearing | C-EFL608ZZ | Precision (JIS): Grade 0 Shield material/shape: Double-sealed type Inner/outer ring material: Steel Basic dynamic load rating (N): 2345 Allowable rotational speed (RPM): 24000 |
1 | SGD 1.71/Unit |
※ Kindly check MISUMI eCatalog for latest information.
Product List
1
2
3
4
※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
