Cutting Unit

Specifications and Features

Purpose/Function

Transport/Movement Supply/Discharge Ejection/Accumulation

1 cylinder 2 operation using cam mechanism
Combining a guide avoidance mechanism using a pusher and cam for cutting, allowing two operations with a single cylinder.
Sequence of operation: ① Cylinder rises ② Cam mechanism shutter opens ③ Work is cut ④ Cylinder returns ⑤ Cam mechanism shutter closes.
A mechanism that links the return guide and pusher, and configures the shutter opening and cutting timing design by the cam mechanism.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Cam Follower	C-CFFR8-19	Screw part nominal (M)(mm): M8x1.25 Material: Carbon steel Fastening method: With screwdriver slot Basic load rating Cr(dynamic)(kN): 3.5 Allowable rotational speed (rpm): 11000	1	SGD 7.53/Unit
②	Linear Bushing - Square Flange	E-LBKM13UU	Inner circle diameter dr(φ): 13 Total length L(mm): 32 Outer tube material: Steel Outer tube surface treatment: Electroless nickel plating	2	SGD 5.38/Unit
③	Set Collar	C-SCSAW16-12	Inner diameter V(mm): 16 Width (mm): 12 Material: Aluminum Surface treatment: White anodizing	2	SGD 3.80/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Cam Followers Straight Slot, Flat SGD 6.60/Unit Shipping: Same Day

2 Square Flanged Linear Bushings, Single / Double / Opposite Counterbored Hole SGD 3.72/Unit Shipping: Same Day

3 Set Collars Clamp Type SGD 2.62/Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
