High-Precision X-Y Table Unit
Specifications and Features
- Purpose/Function
-
Transport/Movement
Positioning/Clamp
Inspection/Measurement
XY table with overrun protection
Medium load, medium-low speed XY table unit
Environment/Operability: For tables used to perform inspection and other tasks on printed circuit boards in a Class 100 clean room, pins are provided for positioning the pallet.
Medium load, medium-low speed XY table unit
Environment/Operability: For tables used to perform inspection and other tasks on printed circuit boards in a Class 100 clean room, pins are provided for positioning the pallet.
※ This example is for design reference only. Equipment components may differ from the actual shape.
| No. | Component | Economy Type Number | Specification | Quantity | Unit Price |
|---|---|---|---|---|---|
| ① | Support Unit-Supported Side | C-TEF10 | Type: Support side Shaft diameter D(φ): 8 Material: Steel Surface treatment: Black oxide coating |
1 | SGD 8.26/Unit |
| ② | Support Unit-Supported Side | C-TEF12 | Type: Support side Shaft diameter D(φ): 10 Material: Steel Surface treatment: Black oxide coating |
1 | SGD 8.32/Unit |
| ③ | Support Unit-Fixed Side | C-TBK12 | Type: Fixed side Shaft diameter D(φ): 12 Material: Steel Surface treatment: Black oxide coating |
1 | SGD 24.22/Unit |
| ④ | Support Unit-Fixed Side | C-TEK10S | Type: Fixed side Shaft diameter D(φ): 10 Material: Steel Surface treatment: Black oxide coating |
1 | SGD 23.82/Unit |
| ⑤ | Coupling | E-LMCPW26-8-8 | Outer diameter A(φ): 26 Allowable torque range (Nm): 2 Allowable eccentricity range (mm): 0.15 Maximum rotational speed (r/min): 10000 |
1 | SGD 11.20/Unit |
※ Kindly check MISUMI eCatalog for latest information.
