Simple Hand Press Unit

A simple hand press using a toggle clamp, with the lateral pressure type arranged vertically and pressed into the forming type. Since the load change during the link process is unclear, select a toggle clamp with enough fastening pressure to accommodate the required load.
In the toggle mechanism, the power-boosting structure often operates near the end of the process at the input point to generate a large load.
Therefore, when using this force for forming, design it to achieve the desired load near the end of the stroke.
Environment/operability: Supports small-volume production through manual operation.
