Film Thermal Cutter

Specifications and Features

Purpose/Function

Assembly/Processing

A mechanism that cuts resin films by controlling the temperature using cartridge heaters.
Mainly used to supply heat locally.
Provides heat accurately and efficiently by achieving optimal performance during the production and manufacturing process.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Components	Economy Type Number	Specification	Quantity	Unit Price
①	Cartridge Heater	E-MCHK6-40-V220-W80	Diameter: 6mm Length: 40mm Rated capacity: 80W	2	SGD 12.80/Unit
②	Temperature Sensor	C-MSND3-30	Protective cover/tube diameter d(φ): 3mm Protective tube length: 30mm	1	SGD 18.14/Unit
③	Insulation Plate	E-HIPLA-70-20-5	Standard type (heat resistance up to 220°C) Length: 70mm Width: 20mm Thickness: 5mm	1	SGD 1.98/Unit
④	Heat Shrink Tube	MTUBE-B-1	Flame resistance: Yes Inner diameter (before shrinkage): 1.5mm Inner diameter (after shrinkage): ≤0.65mm Packaging specification: 100 meters/roll	1	SGD 7.20/Unit
⑤	Temperature Controller	C-MTCTRS	Relay/voltage output freely switchable	1	SGD 40.01/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Cartridge Heaters Standard Type SGD 12.76 /Unit Shipping: Same Day

2 Temperature Sensors High Temperature K-Thermocouple SGD 18.14 /Unit Shipping: Same Day

3 Heat Insulating Plates Normal Grade, Temperature Resistance Within 220 °C SGD 0.79 /Unit Shipping: 11 Days

4 Heat Shrink Tubes Flame Retardant, Shrinkage2:1 SGD 7.20 /Unit Shipping: Same Day

5 Temperature Controllers Standard Type SGD 40.01 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
