Tool Storage Box

Specifications and Features

Purpose/Function

Setup Body/Structure

Jig/tool storage box
Mainly used to store jigs and tools for equipment maintenance and replacement.
Widely used in processing manufacturing such as automation and medical devices.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Handle	C-UPCA120	Material: ABS resin Mounting interval L: 120mm Total height: 39mm	1	SGD 1.90/Unit
②	Adjusting Pad	C-CNFJN10-100	Screw part material: Steel Screw length: 100mm Width: 38mm Screw specification: M10	4	SGD 1.34/Unit
③	Slide Rail	C-SRY27300	Slide rail length: 300mm Stroke: 222mm	6	SGD 12.14/Unit
④	Knob	C-NZWM4-10	Male thread Screw specification: M4 Mounting part length L: 10mm	3	SGD 0.62/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 ABS Plastic Handles With Counterbored SGD 1.50 /Unit Shipping: Same Day

2 Leveling Mounts Metal Pad Standard SGD 1.32 /Unit Shipping: Same Day

3 Slide Rails Two Step Slide Light load Type(Width:27mm, Steel) SGD 8.24 /Unit Shipping: Same Day

4 Straight Grained Knobs SGD 0.62 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
