Storage Rack

Specifications and Features

Purpose/Function

Setup Body/Structure

Shelf for storing jigs and tools.
It is widely used to place jigs, which are equipment for facility maintenance or replacement.
Widely used in processing and manufacturing industries such as automobiles and medical devices.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Trim/Panel	LCPM-500-400-3	Color: Transparent Length: 500mm Width: 400mm Height: 3mm	4	SGD 37.76/Unit
②	Connector	LBJ6-20	Connection frame: No.6-20	40	SGD 0.56/Unit
③	Adjusting Pad	C-CNFJNS10-100	Screw part material: Steel Screw length: 100mm Width: 38mm Screw specification: M10	4	SGD 2.52/Unit
④	Angle Bracket	LBSB8-3030	Frame dimensions: 3030 Cover mounting hole processing addition: None Accessories: None	20	SGD 0.60/Unit
⑤	Casters	C-CJWJ100-P	Wheel material: Polypropylene Wheel diameter: 100mm Mounting height: 129.3mm	4	SGD 6.78/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 PMMA Cover Panel Standard Type SGD 16.96 /Unit Shipping: 7 Days

2 Blind Joints, Pre-Assembly Insertion Double Joint Kits For Aluminum Frames SGD 0.30 /Unit Shipping: Same Day

3 Leveling Mounts Metal Pad Standard SGD 1.32 /Unit Shipping: Same Day

4 Tabbed Brackets For Aluminum Frames SGD 0.38 /Unit Shipping: Same Day

5 PP Casters Swivel Type SGD 5.78 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
