Simple Transfer Guide Device

Specifications and Features

Purpose/Function

Transport/Movement

A transfer guide mounted on an automatic transfer line to reduce production intervals.
Mainly used in conveyors and roller bars, and widely applied in packaging, medical devices, and logistics industries.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Pillar Fixing Clamp	C-HLKDE12	Main diameter: Same diameter Hole diameter: 12mm	4	SGD 3.94/Unit
②	Urethane Roller	C-RORUA30-50	Urethane hardness: Shore 90 (green) Outer diameter 30mm Length: 50mm	40	SGD 14.52/Unit
③	Round Pillar	C-PETR12-40	Outer diameter(φ) 12mm Length: 40mm	4	SGD 1.56/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 One-Touch Strut Clamps SGD 3.94 /Unit Shipping: Same Day

2 Urethane Molded Rollers With Bearings SGD 7.24 /Unit Shipping: Same Day

3 Round Posts Both Ends Tapped SGD 0.90 /Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
