Probe-Type Electrical Characteristics Inspection Device

Specifications and Features

Purpose/Function

Inspection/Measurement

Moves workpieces supplied by a robot onto two workpiece tables and positions the probe holder for inspection.
Widely applied to conduction tests and line tests of electronic circuits in the semiconductor industry.

Probe-Type Electrical Characteristics Inspection Device

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Angle Plate	C-AIKK200-100	Height: 200mm Length: 60mm	1	SGD 66.26/Unit
②	Proximity Sensor	C-2C08-N11	Output type: NPN (normally open) Detection distance: 4.0mm Sensor head specification: M8×1.0mm	2	SGD 16.52/Unit
③	Contact Probe	C-NP58-C	Probe head shape: A type Probe head outer diameter: 0.8mm	2	SGD 36.28/Unit
④	Actuator	C-KS4001-B1-100-F0	Cover: None Base length: 100mm Stage long block: 1 piece Motor accessory: F0	1	SGD 0.00/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Angle Plates Lightweight, High Rigidity Type SGD 35.00 /Unit Shipping: Same Day

2 Proximity Sensor, Long Detection Range, Unshielded, Bend Tolerance, Oil Resistant Cable SGD 15.98 /Unit Shipping: Same Day

3 NP58 Series Contact Probes Min Pitch 1.00mm, Stroke 2.0mm SGD 36.28 /Unit Shipping: Same Day

4 Single Axis Actuators KS40 Standard/KSC40 With Cover SGD 367.87 /Unit Shipping: 5 Days

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
