Sheet Metal Bending Jig

Specifications and Features

Purpose/Function

Assembly/Processing

Simple sheet metal bending jig consisting of a toggle clamp and an index plunger.
Simple structure and easy to operate.
Various positioning jigs can be configured using different positioning and clamping products such as toggle clamps and index plungers.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Index Plunger	C-PMXSB10	Locking mechanism: Return type Surface treatment: Black oxide treatment Screw outer diameter: M10	1	SGD 3.02/Unit
②	Ball Plunger	C-PFPPN3-20P	Outer diameter: M3 Stroke: 0.6mm	2	SGD 9.68/Unit
③	Toggle Clamp	C-LD-301AM	Horizontal type: 1568N	2	SGD 3.30/Unit
④	Linear Guide	E-GMLG7-55	Model Number: 7 Length: 55mm	1	SGD 14.98/Unit

※ Kindly check MISUMI eCatalog for latest information.
