Multi-Directional Adjustment Unit

Specifications and Features

Purpose/Function

Positioning/Clamping Inspection/Measurement

"Multidirectional manual stage adjustment unit.
The structure of the position adjustment unit is simple and position adjustment is easy.
Widely used in mechanical equipment or process equipment that require various positioning and adjustments.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Locating Pin	C-JPBB6-8	Insertion end shape: Circular Mounting end outer diameter: 6mm Positioning end outer diameter: 8mm	4	SGD 2.70/Unit
②	Adjusting Screw	C-AJKTNA6-30	Screw diameter × pitch: M6×1.0 Screw length: 30mm	2	SGD 2.78/Unit
③	Bush for Locating Pin	C-JBHM10-8	Inner diameter: 10mm Outer diameter: 15mm Length: 8mm	2	SGD 5.72/Unit
