Timing Pulley Drive Transfer Mechanism

Specifications and Features

Purpose/Function

Transport/Movement

A mechanism that moves and transports products by rotating a timing pulley and using a timing belt and linear guide.
The timing pulley structure is compact, with high power transmission efficiency and stable power transmission.
It not only has low noise but also can absorb shocks and vibrations.
It can transmit power over relatively large center distances

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Photo Sensor - Groove Type	C-MSX672N	Shape: T-type Output state: PNP type (normally open)	3	SGD 4.95/Unit
②	Timing Pulley T5	C-TTPA22T5100-A-P8	Pulley shape: A shape Belt nominal width: 100 (10mm) Number of teeth: 22 Round hole (shaft hole diameter 8mm) + tap	1	SGD 7.24/Unit
③	Mechanism for Open-End Timing Belt	C-TBCR-T5100	Belt specification: T5 Belt width: 10mm	1	SGD 3.48/Unit
④	Timing Belt	C-TTBN1100T5-100	Belt nominal width: 100 (10mm) Belt circumference: 1100mm	1	SGD 5.57/Unit
⑤	Idler T5	C-AHTFW20-T5100-8	Both sides bearing type Belt nominal width: 100 (10mm) Number of teeth: 20 Shaft hole diameter: 8mm	1	SGD 14.92/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Photo Microsensors, Connector Type SGD 4.95/Unit Shipping: Same Day

2 Timing Pulleys T5 SGD 6.28/Unit Shipping: Same Day

3 Clamp Plates for Open End Belts T Type SGD 3.48/Unit Shipping: Same Day

4 Timing Belts T5 SGD 1.10/Unit Shipping: Same Day

5 Idlers T5 SGD 8.60/Unit Shipping: Same Day

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
