Hole Depth Inspection Jig

Specifications and Features

Purpose/Function

Inspection/Measurement

Case study of a hole depth inspection jig
Used to check whether the hole depth machining of a part with die-cast grooves meets the design requirements.
Extract the product and proceed with inspection.

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Oilless Bushing	C-MUTZ8-20	Mounting method: Circular flange type Inner diameter: 8mm Total length: 20mm	6	SGD 8.20/Unit
②	Set Collar	C-SCSAW20-12	Inner diameter: 20mm Thickness: 12mm Outer diameter: 40mm	2	SGD 4.20/Unit
③	Shaft Holder	C-SHFMQ20	Inner diameter: 20mm	4	SGD 4.52/Unit
④	Linear Guide	E-GMLG15-390-B2	Nominal model number: 15 Length: 390mm	2	SGD 54.84/Unit
⑤	Linear Bushing	C-LMF20UU	Inner diameter: 20mm Outer diameter (ø): 32mm Total length: 42mm	4	SGD 4.46/Unit
⑥	Shaft	E-PSFJT20-210-M6	Shaft diameter: 20mm Length: 210mm Screw specification: M6	4	SGD 11.20/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Oil Free Bushings Copper Alloy Flanged I.D.F7/O.D.h7 SGD 6.39 /Unit Shipping: Same Day

2 Shaft Collars Clamp Type SGD 2.62 /Unit Shipping: Same Day

3 Shaft Supports Flanged Slit, Reinforced SGD 2.94 /Unit Shipping: Same Day

4 Miniature Linear Guides Standard SGD 9.48 /Unit Shipping: Same Day

5 Round Flanged Linear Bushings, Single / Double / Opposite Counterbored Hole SGD 3.32 /Unit Shipping: Same Day

6 Linear Shafts One End Tapped SGD 3.10 /Unit Shipping: 7 Days

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
