Multi-Degree of Freedom Semi-Automated Adjustment Connection System

Specifications and Features

Purpose/Function

Transport/Movement

Case study of a multi-degree-of-freedom semi-automated adjustment linkage system
Applicable to guide mechanisms with relatively small mounting spaces for connecting medium/low precision assemblies or sub-assemblies with moderate loads

Multi-degree of freedom semi-automated adjustment connection system

※ This example is for design reference only. Equipment components may differ from the actual shape.

No.	Component	Economy Type Number	Specification	Quantity	Unit Price
①	Support Unit - Fixed Side	C-TEK10	Shaft diameter (ø): 10mm	1	SGD 23.80/Unit
②	Trapezoidal(Lead) Screw	C-MTSR8-240	Material: Steel Screw diameter (ø): 8mm Shaft total length: 240mm	1	SGD 5.33/Unit
③	Linear Guide	E-GMLG15-670-B2	Assembly height: 15 Length: 670mm Additional purchase: Block only	2	SGD 75.31/Unit
④	Support Unit - Supported Side	C-TEF10	Shaft diameter (ø): 10mm	1	SGD 8.26/Unit
⑤	Actuator	C-KS4001-B1-100-F1-W1	Cover: None Base length: 100mm Stage long block: 1 piece Motor accessory: F1	1	SGD 411.10/Unit

※ Kindly check MISUMI eCatalog for latest information.

Product List

1 Support Units for Ball Screw, Fixed Side Square Type SGD 23.10 /Unit Shipping: Same Day

2 Lead Screws-Straight SGD 1.28 /Unit Shipping: 7 Days

3 Miniature Linear Guides Standard SGD 9.48 /Unit Shipping: Same Day

4 Support Units for Ball Screw, Support Side Square Type SGD 8.16 /Unit Shipping: Same Day

5 Single Axis Actuators KS40 Standard/KSC40 With Cover SGD 367.87 /Unit Shipping: 5 Days

※ The price on the product list is the starting price for that product.
Product details (Price, leadtime and availability) may be subjected to updates.
Kindly check MISUMI eCatalog for latest information.
